Kyocera SGS #2 Di-Namite Solid Carbide High Performance Drill

High performance drill offers application benefits beyond that of other high-performance drills. Each feature of this design was engineered around the challenges of drilling composite materials. The series 120 portfolio leads the industry in hole performance with no splintering or delamination.

Brand :Kyocera SGS

Cutting Diameter (in) :0.2210

Manufacturer Part Number :50016

Cutting Diameter (mm) :5.61

Features & Benefits : 3xD reach
2 flute design
Normal shank
20 helix angle
145 drill point
External coolant
Series 120
Double margin design stabilizes the drill for greater hole accuracy and improved surface finish
Notched point reduces thrust force over conventional designs
8 facet point reduces fibre breakout and delamination on exit
90 degree secondary chamfer angle improves hole entrance and exit quality

Material :Solid Carbide

Coating/Finish :Di-Namite (Diamond)

Overall Length (in) :2-5/8

Flute Length (in) :1.0

Shank Length (in) :1-7/16
